Epson SureColor T3170M 24" Wireless Printer with Integrated Scanner
Print:
Printing Technology: PrecisionCore MicroTFP 4-channel, drop-on-demand printhead
Maximum Print Resolution: 2400 x 1200 dpi
Print Speed: A1/D-sized print: 34 seconds1
Minimum Ink Droplet Size: Smallest Droplet Size: 4 picoliters; Variable Droplet Technology can produce up to three different sizes per line
Nozzle Configuration:
- Black: 800 nozzles (800 nozzles x 1 channels)
- Color: 2400 nozzles (800 nozzles x 3 channels)
General:
Operating Systems:
- Mac® OS X® (10.6.8 or later)9
- Windows® 10, 8.1, 7 (32-bit, 64-bit)9
Temperature:
Storage: -4 ˚ to 104 ˚F (-20 ˚ to 40 ˚C)
Humidity:
- Operating: 20–80% (no condensation)
- Operating (Recommended): 45–60% (no condensation)
- Storage: 5–85% (no condensation)
- Operating: 50 ˚ to 95 ˚F (10 ˚ to 35 ˚C)
- Operating (Recommended): 59 ˚ to 77 ˚F (15 ˚ to 25˚C)
- Without Stand: 38.1" x 11.5" x 19.9"
- With Stand 38.1" x 19.5" x 46.9
- Without Stand: 75 lbs (34 kg)
- With Stand: 102.3 lb (46.5 kg)
Security:
IEEE802.1x, SNMP 3, TLS/SSL, SMTPs, POPs, FTPs, IPsec, Administrator Mode, WPA3
Safety Approvals:
USA and Canada (NRTL Certified, CSA/UL 62368-1)
Country of Origin:
Indonesia
Warranty:
Standard 1-year, Customer Care telephone support Monday through Friday and/or whole unit exchange**
General:
- Maximum Copies: Up to 99
- Reduction/Enlargement: 25% to 400%
- Auto Sheet Feeder: Up to 11" x 17"
- Sheet Feeder Capacity: 50 pages
- Memory: 1GB (Printer) + 8GB (Scanner)
- Acoustic Noise Level
- Operating: Approx. 47 dB(A)
- Sleep: Approx. 32 dB(A)
- Media Type: Plain Paper, Recycled Paper, Coated Paper, Tracing Paper, Film, Blueprint, Offset Printing Paper, Carrier Sheet
- Supported File Formats: JPEG, PDF (Single Page), PDF (Multi-Page), PDF/A, Encrypted PDF, TIFF
Ink Supply System:
In-box Ink Fill Volume:
- Colors (C,M,Y) 26 mL6
- Black (K) 50 mL6
- Colors (C,M,Y): 26 or 50 mL6
- Black (K): 50 or 80 mL6
- 2 years from printed production date or 6 months after opened
- Printer is designed for use with Epson cartridges only, not third-party cartridges or ink.*
Printable Area and Accuracy:
Maximum Paper Width:
24"
Minimum Cut-sheet Size:
8.27 x 11" (1 sheet and ASF)
Minimum Paper Width:
- Roll: 13"
- Sheet: 8.26"
Line Accuracy:
±0.1% or ±0.26 mm
Maximum Printable Length:
Up to 59'8
Specifications Scanner:
Sensor:
CIS Sensor (Sheetfed)
Maximum Resolution:
Up to 600 dpi, reprint 2400 x 2100 dpi
Color and Grayscale Scan Mode (Bit Depth):
Scan to Network Folder, FTP Server, Secure FTP Server, Mail Server, Secure Mail Server, USB Memory Stick
Maximum Scan Area:
- Width: Up to 24"
- Length: Up to 8.9'
- Up to 1.5 ips (Color)
- Up to 4.5 ips (Monochrome)
Sheet Media Handling:
Thickness: 10.2 mil
Single Sheet, Top-loading: Up to 24" wide
Left/Right Margins: Minimum 3 mm each
Roll Media Handling:
Single Roll-to-Roll / Top-loading Roll: 24" wide
Media Core: 2" Core Diameter: User-adjustable roll media adapters
Maximum Roll Diameter: Up to 4.6"
Maximum Roll Weight: 6.6 lb
Media Thickness: Up to 8.6 mil
Roll Cutting: High-speed internal rotary cutter; auto or manual7
Roll Paper Remaining: The amount of remaining paper can be controlled from the control panel
Printer Details:
Display: 4.3" Touchscreen
Printer Language:
- ESC/P raster
- HP-GL/2, HP RTL *1
Interfaces:
SuperSpeed USB*1, Wired Ethernet 100BASE-TX /1000BASE-T, Wireless LAN IEEE802.11 b/g/n, USB memory stick, Wi-Fi Direct
Power:
Power Consumption:
- Printing: Approx. 24 W
- Ready: Approx. 11 W
- Sleep: Approx. 2 W
- Power Off (Stand By): 0.2 W
- Voltage: AC 110–240 V
- Frequency: 50–60 Hz
- Current: 1.4 A
