Print
- Printing Technology: Advanced PrecisionCore® TFP® 12-channel drop on demand, inkjet printhead with ink-repelling coating technology
- Ink Type: UltraChrome RS ink; 6-color+ Optimizer
- Production Edition Ink Configuration: C, M, Y, K, LC, LM, OP, ML
- Nozzle Configuration: Color and monochrome heads; 1,600 nozzles x 2
- Droplet Technology: Variable Droplet Technology
- Maximum Resolution: 1200 x 2400 dpi
- Printer Language/Drivers: Epson ESC/P® raster
Epson Ink Supply System
- Ink Supply Tank Fill Volume: 1,500 mL x 2 each color; 6 colors total
- Ink Pack Shelf Life: 2 years from printed production date
- Printer is designed for use with Epson ink packs only, not third party ink systems*
Roll Media Handling
- Single Roll-to-roll: 64" wide
- Media Core: 2" or 3" core diameter
- Maximum Roll Diameter: Up to 9.8"
- Maximum Roll Weight: Up to 100 lb
- Media Thickness: 1 mm thick
- Take-up Reel: Fully automatic “wind in” or “wind out” with tension control
Printable Area and Accuracy
- Maximum Paper Width: 64"
- Minimum Paper Width: 11.8"
- Left/Right Margins: 0.20" (0.40" total)
- Maximum Printable Width: Up to 63.6"
General
- Weight and Dimensions (W x D x H): 116" x 41" x 70" (2,949 mm x 1,045 mm x 1,774 mm)
- Weight: 990 lbs (449kg)
- Acoustic Noise Level: Approx 66.1 dB
- Temperature Operating: 59 F to 86 F (15 C to 30 C)
- Relative Humidity Operating: 20 – 80% (no condensation)
- Operating (recommended): 40 – 60% (no condensation)
- Electrical Requirements: Printer: Requires two outlets
Printer Interfaces
- Hi-Speed USB 2.0 (1 port)
- 1000Base-T Ethernet (1 port)
- Operating Systems Supported: Windows® 10 and 8.1
- Epson Edge Print: Minimum PC Requirements: 2GHz CPU, 2GB RAM, 120GB HDD, DVD-ROM or Internet connection
- Recommended PC Specifications: 3GHz or higher quad core CPU, 8GB RAM, 500GB SSD, and high-speed Internet connection
General (Continued)
- Voltage: AC 200-240 V
- Frequency: 50/60 Hz
- Current: 16 A x 2
- Power Consumption:
- Printing: Approx 4.6 kW
- Standby: Approx 220 W
- Sleep Mode: Approx 44 W
- Power Off: Approx 1.0 W
- Limited Warranty and Service: Standard 1-year limited warranty. Optional Epson Service programs available for a total of 3 years of coverage.
- Country of Origin: China
Eco Features
- GREENGUARD Certified
- WEEE Compliant
- RoHS Compliant
- REACH Compliant
