Epson SureColor F2000W White Edition Direct to Garment Printer

Print:

Printing Technology:

Advanced PrecisionCore TFP Print Head

Maximum Print Resolution:

Up to 1440x1440 dpi for White Ink

Up to 1440x720 dpi for Color Ink

Nozzle Configuration:

8 Channels of 360 Nozzles

6 Ink Cartridge Bays

Ink:

Replacement Ink:

Black Cartridge (600 ml): T725100

Cyan Cartridge (600 ml): T725200

Magenta Cartridge (600 ml): T725300

Yellow Cartridge (600 ml): T725400

White Cartridge (600 ml): T725A00

General:

Operating Systems:

Apple® MacOS 10.12, OS X 10.11, 10.10

Garment Media Handling:

Thickness:

Garments up to 0.98” Thick

Media Type:

100% Cotton or cellulose fiber garment recommended

Maximum Print Area:

Maximum Printing Area 16” x 20” (Optional Large Platen)

Supported File Formats:

Tiff and PNG recommended for support of transparency

JPG and BMP

Curing Requirements:

Heat Press Times:

White Only: 45 sec/6 PSI

Colour Only: 45 sec/6 PSI

White & Colour: 75 sec/6 PSI

Use more time for heavy coverage on large areas

Heat Press Temperature:

Heat Press Temp - 338°F/170°C

Heat Conveyer Times:

Heat Conveyer Temp - 320°F/160°C

Heat Conveyer Temperature:

White Only: 3.5 to 4.5 min

White & Color: 4.5 to 5.0 min

Printer Details:

Software Included:

Garment Creator Application

Epson Professional Communication Driver for Windows

Epson LFP Remote Panel

Interfaces:

10/100Base-T Ethernet and USB 2.0

Power:

Power Supply Voltage:

AC 100-240 V

Rated Frequency:

50-60 Hz

Power Consumption:

Approx. 52W

Approx. 20W

Approx. 10W

Rated Current:

0.4-0.7A
